Product Description
Technical Parameters
| Type | BL-3D-81000 Parameter | |
| Applicable Wire Dia. | Soft material Φ:3.0-10.0mm Hard material Φ:3.0-8.0mm |
|
| Bending stroke | 850mm | |
| Number of control Axis | 8 Axis | |
| Total power | 20.6KW | |
| Power Of wire turning Motor | 2.7KW | |
| Power of wire feeding motor | 5.5KW | |
| Power Of Angle control Motor | 2.0KW | |
| Inner/outer angle motor power | 2.7KW/2.7KW | |
| Power of the lifting motor for the pallet | 1.0KW | |
| Power Of Wire Cuter Motor | 2.0KW | |
| Left and right translation motor power | 2.0KW | |
| Maximum wire feeding speed | 40m/min | |
             Wire feeding accuracy |
300mm±0.1mm | |
| Angle accuracy | 90°±0.1mm | |
| Input Power | 380V/50Hz/3Ph | |
| Machine Size(L*W*H) | 3800KG | |
| Machine Size(L*W*H) | 4420mm*2100mm*1600mm | |
| Automatic feeder | Maximum load Weight: | 1500KG |
| Size (L*W*H) | 2100mm*2100mm*1300mm | |
Product Advantages
1、The principle of the wire bending machine is that the line does not turn, the production is faster.
The production line by 3.0-10.0mm, car seat frame steel wire parts and kitchen wire and other production tools.
2、There is a lifting platform in front, long and short linear products are suitable for production, the overall structure is very intuitive.
3、Easy to debug, can be produced in the shape of plane and three-dimensional wire,
4、Computer has Chinese and English language, easy to switch between export and domestic sales,flexible and convenient operation.
Product Application
Products are mainly Used In Automobiles, Kitchenware, Garden Tools, Supermarket Shelves, Furniture, etc.
Wire Bender Videos
Wire Forming Drawing
Manufacturing Capacity
Belang automation equipment co., LTD. is an innovative technology enterprise integrating r&d, manufacturing, sales and system integration services. Focusing on providing customers with solutions for high-precision 3D wire forming equipment, we are committed to promoting the transformation and upgrading of China's manufacturing industry to intelligent manufacturing.
